Specification
Specifications:
Overall Size | Max Capacity | Way to Install |
115*86*23 | 1core | Wall Mounting(Indoor) |
135*86*20 | 1core | Wall Mounting(Indoor) |
160*48*18 | 1core | Wall Mounting(Indoor) |
86*86*27 | 2core | Wall Mounting(Indoor) |
100*80*22 | 2core | Wall Mounting(Indoor) |
105*82.5*22.5 | 2core | Wall Mounting(Indoor) |
123*80*27 | 2core | Wall Mounting(Indoor) |
150*110*33 | 4core | Wall mounting(indoor/outdoor) |
150*110*48 | 8core | Wall mounting(indoor/outdoor) |
Items | Description | Items | Description |
Available Cable | 3.1mm*2.0mm rubber fiber cable | Installation Way | Fixed by screw |
Insertion Loss | <0.5dB | Size | 86mm*86mm*22mm |
Reflection Loss | ≥45dB (PC panel) ≥60dB(APC panel) | Dimension(LxWxH)MM | 105.4*82.4*22.5 |
Tensile Strength | >20N | Installation | Wall Mounting(Indoor/Outdoor) |
Outlet No. | 2 | Cable Entries | Supporting Uncut |
Material | With fire-proof ABS plastic | Max Cable Diameter | Max Input=2.0*5.0mm |
Adaptor | SC | No.Of Adaptor&Splitter | 2pc SC asaptor or 2pc Double LC |
Note:
We supply OEM&ODM service.
