Super Lowest Price Tactical Optical Cable - 4-24 Core Single Mode Anti-Rodent Fiber Optic Cable With G652（缺少产品图片） – GL Technology

That has a positive and progressive attitude to customer's interest, our organization consistently improves our products quality to satisfy the demands of shoppers and further focuses on safety, reliability, environmental specifications, and innovation of Fiber Optic Cable Type , Drop Wire , Outdoor Sm Waterproof Fiber Optic Pigtail , We aim at Ongoing system innovation, management innovation, elite innovation and market innovation, give full play to the overall advantages, and constantly improve service quality.

---

Super Lowest Price Tactical Optical Cable - 4-24 Core Single Mode Anti-Rodent Fiber Optic Cable With G652（缺少产品图片） – GL Technology Detail:

For the GYXS Anti rodent fiber optic cable , the single mode or multimode optical fibers are put into the central tube made of high modulus polyester. The tube is full of the waterproof filling compound. It is armoured by a circle of steel wire which provide an excellent pressure resistant performance. Outside is wrapped longitudinally by a layer of waterproof tape and steel tape.

Optical Fiber Type and Properties

Item		Unit	Specification
			G. 652
Mode Field Diameter	1310nm	mm	9.2 ± 0.4
	1550nm	mm	10.4 ± 0.8
Cladding Diameter		mm	125.0 ± 1
Cladding Non-circularity		%	£1.0
Core Concentricity Error		mm	£0.5
Coating Diameter		mm	242 ± 7
Coating/Cladding Concentricity Error		mm	£12
Cable Cut-off Wavelength		mm	£ 1260
Attenuation Coefficient	1310nm	dB/km	£0.4
	1550nm	dB/km	£0.3
Proof Stress Level		kpsi	≥100

Dimensions of Cable Constructions

Fiber count	Fibers per tube	Loose tube diameter（mm）	Wire diameter （mm）	Thickness of outer jacket（mm）	Cable diameter（mm）	Cable weight（kg/km）
4	4	2.4±0.1	0.9	1.6±0.1	9.2±0.5	125
8	8	2.4±0.1	0.9	1.6±0.1	9.2±0.5	125
12	12	2.4±0.1	0.9	1.6±0.1	9.2±0.5	125
24	24	3.2±0.1	0.9	1.6±0.1	10.0±0.5	150

Notes:

Only a part of Joint Box/Splice Closure/Joint Closure are listed here. We can depend on customer’s requirement to producing the different model Joint Box/Splice Closure/Joint Closure.
We supply OEM&ODM Service.    Contact Us Now !
E-Mail: [email protected]
WhatsApp:+86 18073118925             Skype: opticfiber.tim

---

Product detail pictures:

Related Product Guide:

---

We always get the job done to be a tangible staff to ensure that we can easily offer you the best high-quality and the greatest value for Super Lowest Price Tactical Optical Cable - 4-24 Core Single Mode Anti-Rodent Fiber Optic Cable With G652（缺少产品图片） – GL Technology, The product will supply to all over the world, such as: Lisbon , Italy , Monaco , All our staffs believe that: Quality builds today and service creates future. We know that good quality and the best service are the only way for us to achieve our customers and to achieve ourselves too. We welcome customers all over the word to contact us for future business relationships. Our products are the best. Once Selected, Perfect Forever!
