Low MOQ for Gyts53 - GYTS Stranded Loose Tube Cable with Steel Tape – GL Technology Detail:

Application:

Aerial/Duct/Outdoor

Characteristic:

1，The following measures are taken to ensure the water blocking performance of the cable.
2，Single steel wire used as the central strength member.
3，Special water-blocking filling compound in the loose tube.
4，100% cable core filling.

Temperature Rage：

Operating :-40℃ to +70℃
Storage :-40℃ to +70℃

Standards：

Comply with standard YD/T 901-2009 as well as IEC 60794-1

Specification

Technical Parameters：

Cable Type (increased by 2fibers)	Fiber Count	Cable Diameter (mm)	Cable Weight (kg/km)	Tensile Strength Long/Short Term (N)	Crush Resistance Long/Short Term (N/100mm)	Bending Radius Static/Dynamic (mm)
GYTS 2 ~ 30	2 ~ 30	9.5	80	600/1500	300/1000	10D/20D
GYTS 32 ~ 36	32 ~ 36	9.7	97	600/1500	300/1000	10D/20D
GYTS 38 ~60	38 ~60	10.5	109	600/1500	300/1000	10D/20D
GYTS 62 ~72	62 ~72	11.5	126	600/1500	300/1000	10D/20D
GYTS 74 ~96	74 ~96	13.2	153	600/1500	300/1000	10D/20D
GYTS 98 ~120	98 ~120	14.6	182	600/2000	300/1000	10D/20D
GYTS 122 ~ 144	122 ~ 144	16.5	221	600/2500	300/1000	10D/20D
GYTS 146 ~ 216	146 ~ 288	16.5	221	600/2500	300/1000	10D/20D

Noted:

1，Only a part of Aerial/Duct/Direct Buried/UnderGround/Armoured cables are listed in the table. Cables with other specifications can be inquired.
2，Cables can be supplied with a range of single mode or multimode fibers.
3，Specially designed Cable structure is available on request.

Write your message here and send it to us

Product detail pictures:

Related Product Guide:

No matter new customer or outdated client, We believe in extensive phrase and trusted relationship for Low MOQ for Gyts53 - GYTS Stranded Loose Tube Cable with Steel Tape – GL Technology, The product will supply to all over the world, such as: Wellington , Turkey , Mongolia , We solution have passed through the national skilled certification and been well received in our key industry. Our specialist engineering team will often be ready to serve you for consultation and feedback. We are able to also provide you with no cost samples to meet your needs. Best efforts will be produced to offer you the very best service and solutions. For anyone who is considering our business and solutions, please speak to us by sending us emails or get in touch with us right away. As a way to know our products and enterprise. lot more, you'll be able to come to our factory to find out it. We will constantly welcome guests from around the globe to our firm. o build enterprise. elations with us. Please really feel absolutely free to make contact with us for small business and we believe we will share the top trading practical experience with all our merchants.

Optical Cable Factory

In 2004, GL FIBER established the factory to produce optical cable products, mainly producing drop cable, outdoor optical cable, etc.

GL Fiber now have 18 sets of coloring equipments, 10 sets of secondary plastic coating equipments, 15 sets of SZ layer twisting equipments, 16 sets of sheathing equipments, 8 sets of FTTH drop cable production equipments, 20 sets of OPGW optical cable equipments, and 1 paralleling equipment And many other production auxiliary equipments. At present, the annual production capacity of optical cables reaches 12 million core-km (average daily production capacity of 45,000 core km and kinds of cables can reach 1,500 km) . Our factories can produce various types of indoor and outdoor optical cables ( such as ADSS, GYFTY, GYTS, GYTA, GYFTC8Y, air-blown micro-cable, etc.). the daily production capacity of common cables can reach 1500KM/day, the daily production capacity of drop cable can reach max. 1200km/day, and the daily production capacity of OPGW can reach 200KM/day.
